MyALARM3 Cloud



The smart control and monitoring solution for installations, applications and unattended sites

The family of remote alarm units reaches the third generation! After 10 years since the first MyALARM model, we present an innovative device complete with a mobile control app in 10 languages. MyAlarm3 Cloud is a system composed of a GSM/GPRS intelligent control unit and a mobile app for remote control of houses, plants, machinery and unmanned installations. MyAlarm3 Cloud is a compact and reliable all-in-one system for residential or industrial applications, especially for automatic data and alarm sending from unattended sites.
The mobile app offers the main functions useful for monitoring through an immediate consultation and practical use from iOS and Android mobile devices, allowing the management of alarms (in case of a blackout, digital contacts variation, analog inputs and temperature thresholds overcoming), timed, impulsive and on/off commands (lights, motors, gates, pumps, overhead doors, HVAC system contacts and twilight contacts), GPS (position notifications, virtual fence alarm).
(*) The MyALARM3 Cloud system requires a data SIM or a voice/data SIM to activate and use the mandatory Cloud service.
SIM data: The product comes with a V-SIM Vodafone card to be activated. Please follow the coupon inside the package for information on monthly costs, data traffic, and V-SIM activation. Alternatively, you can use a data or voice/data SIM card in your possession. SENECA Cloud Service: With the purchase of the product is included a usage fee of 12 months from the date of the first activation; at the end of the period you can renew the service at a very reasonable cost / year.
Categories: , ,

Description

TECHNICAL DATA

ORDER CODE : MyAlarm3 Cloud
BUILT-IN MODEM: GSM / GPRS quadband
USB INTERFACE: microUSB
EXPANDABLE MEMORY: Slot Micro SD (up to 32 GB)
BUILT-IN MEMORY: Flash (1 + 8 MB)
INTEGRATED TEMPERATURE PROBE: NTC
DIGITAL INPUT: N°4 channels
COUNTERS: N°4 (@32 bit, max 30 Hz)
DIGITAL OUTPUT: N°2 SPST 3 A relay
ANALOG INPUT: N°2 channels (0..20 mA, 0..30 V), 16 bit resolution
SIM CARD: The sim is mandatory for configuration, consultation and use of the system. Each KIT is equipped with a V-SIM Vodafone to be activated via smartphone; alternatively it is possible to use a SIM of the most famous telephone operators.
CONFIGURATION: iOS / Android mobile app Web browser HTML5
INFORMATION STATUS AND USE: iOS / Android mobile app Web browser HTML5 (notifications non available)
CLOUD SERVICE: 12 months included in the purchase price and active from the date of activation of the product
POWER SUPPLY: Through USB cable or 230V AC power supply (both included)

SHIPPING AND EXPORT INFORMATION

PRODUCT CODE MY3CLOUD-R-0-0-G
GROSS WEIGHT kg 0.46
ORIGIN IT
CN (COMBINED NOMENCLATURE) 85176200
ECCN 5A991
